Wiring Schematic for Solar Power System with back-up Generator

Suggested Connection Steps:

  1. Locate batteries and connect in parallel (for 12 Volt cells)
  2. Connect to Inverter
  3. Connect Inverter to Mains Consumer Unit and test
  4. Connect Solar Control Unit to batteries (16ml fused cable)
  5. Mount Solar PV modules and wire in parallel (16ml
  6. Connect Solar Array to Controller and test
    (cover array if short circuit likely).
    7.
